Biostar H610MHC 2.0 motherboard Intel H610 LGA 1700 micro ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-1700 |
|---|---|
| Greutate: | 0.7 kg |
| EAN: | 4712960688278 |
| Compatible processor series: | Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i3 12th Gen, Intel Core i3 14th Gen, Intel® Celeron®, Intel Core i7 13th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i9 14th Gen, Intel Core i3 13th Gen, Intel Core i9 13th Gen |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1700 |
| DirectX version: | 12.0 |
| On-board graphics card: | Yes |
| HDCP: | Yes |
| Motherboard chipset: | Intel H610 |
| Product colour: | Black |
| Audio chip: | Realtek ALC897 |
| PC health monitoring: | Voltage, Fan, Temperature |
| Audio output channels: | 7.1 channels |
| Motherboard chipset family: | Intel |
| Motherboard form factor: | micro ATX |
| Windows operating systems supported: | Windows 10 x64, Windows 11 x64 |
| Supported memory clock speeds: | 2133, 2400, 2933, 3200 MHz, 2666, 1866 |
| Maximum internal memory: | 64 GB |
| Supported memory types: | DDR4-SDRAM |
| Number of memory slots: | 2 |
| Memory channels: | Dual-channel |
| ECC сompatibility: | Non-ECC |
| Memory slots type: | DIMM |
| Width: | 185 mm |
| Depth: | 226 mm |
| LAN controller: | Realtek RTL8111H |
| Wi-Fi: | No |
| Ethernet LAN: | Yes |
| Ethernet interface type: | Gigabit Ethernet |
| Number of SATA III connectors: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| Front panel connector: | Yes |
| Number of chassis fan connectors: | 1 |
| CPU fan connector: | Yes |
| USB 2.0 connectors: | 1 |
| EPS power connector (8-pin): | Yes |
| Front panel audio connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Number of EPS power connectors (8-pin): | 1 |
| BIOS type: | UEFI AMI |
| Cables included: | SATA |
| Drivers included: | Yes |
| Supported storage drive interfaces: | M.2, SATA III |
| Supported storage drive types: | HDD & SSD |
| USB 2.0 ports quantity: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
| Ethernet LAN (RJ-45) ports: | 1 |
| HDMI ports quantity: | 1 |
| HDMI version: | 1.4 |
| Microphone in: | Yes |
| VGA (D-Sub) ports quantity: | 1 |
| PCI Express x1 (Gen 3.x) slots: | 1 |
| Number of M.2 (M) slots: | 1 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
