Asrock Phantom Gaming B850M Riptide WiFi AMD B850 Socket AM5 micro ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-AM5 |
|---|---|
| Greutate: | 1.48 kg |
| EAN: | 4711581490482 |
| Processor manufacturer: | AMD |
| Compatible processor series: | AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series |
| Supported processor sockets: | Socket AM5 |
| Processor socket: | Socket AM5 |
| Maximum resolution: | 3840 x 2160 pixels |
| HDCP: | Yes |
| Parallel processing technology support: | Not supported |
| Motherboard chipset: | AMD B850 |
| Product colour: | Black |
| Windows operating systems supported: | Windows 11 x64, Windows 10 x64 |
| Audio output channels: | 7.1 channels |
| Motherboard chipset family: | AMD |
| Audio chip: | Realtek ALC1220 |
| Motherboard form factor: | micro ATX |
| Certification: | FCC, CE, ErP/EuP |
| ECC сompatibility: | ECC & Non-ECC |
| Maximum internal memory: | 256 GB |
| Number of memory slots: | 4 |
| Supported memory types: | DDR5-SDRAM |
| Memory slots type: | DIMM |
| Unbuffered memory: | Yes |
| Memory channels: | Dual-channel |
| Width: | 244 mm |
| Depth: | 244 mm |
| LAN controller: | Dragon RTL8125BG |
| Bluetooth: | Yes |
| Top Wi-Fi standard: | Wi-Fi 7 (802.11be) |
| Bluetooth version: | 5.4 |
| Wi-Fi: | Yes |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| Wi-Fi standards: | 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 6E (802.11ax) |
| Ethernet LAN: | Yes |
| Number of CPU fan connectors: | 2 |
| Number of RGB LED pin headers: | 1 |
| Number of EPS power connectors (8-pin): | 1 |
| Number of SATA III connectors: | 4 |
| EPS power connector (8-pin): | Yes |
| ATX Power connector (24-pin): | Yes |
| Front panel audio connector: | Yes |
| Number of chassis fan connectors: | 3 |
| RGB LED pin header: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 3 |
| 12V power connector: | Yes |
| TPM connector: | Yes |
| CPU fan connector: | Yes |
| USB 2.0 connectors: | 2 |
| BIOS type: | UEFI AMI |
| M.2 standoff included: | Yes |
| Screws included: | Yes |
| Antenna included: | Yes |
| Cables included: | SATA |
| RAID levels: | 0, 1, 10 |
| RAID support: | Yes |
| Supported storage drive types: | HDD & SSD |
| Number of storage drives supported: | 7 |
| Supported storage drive interfaces: | PCI Express 4.0, PCI Express 5.0, SATA III |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 1 |
| Line-in: | Yes |
| Microphone in: | Yes |
| HDMI ports quantity: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
| DisplayPort version: | 1.4 |
| USB connector type: | USB Type-C, USB Type-A |
| USB 2.0 ports quantity: | 4 |
| Headphone outputs: | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 1 |
| DisplayPorts quantity: | 1 |
| HDMI version: | 2.1 |
| WiFi-AP antenna jack: | 2 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| 1st M.2 highest PCI Express generation: | 5.0 |
| 3rd M.2 largest key size: | 2280 |
| 1st M.2 largest key size: | 2580 |
| 2nd M.2 largest key size: | 2280 |
| 3rd M.2 highest PCI Express generation: | 4.0 |
| PCI Express x8 (Gen 4.x) slots: | 1 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| Number of M.2 (M) slots: | 3 |
| Warnings: | Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste. |
