STAG EV CORE Charging Station (without charging cable)
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | DC charging stations |
|---|---|
| Greutate: | 4.3 kg |
| EAN: | 5903022040922 |
| PSTI certified: | No |
| Product supplier data: | Brand: STAGEV; Manufactured: AC S.A., Address: ul. 42 Pułku Piechoty 50, 15‑181 Białystok, Poland; Website: www.stag-ev.com |
| Safety notices link: | https://www.stag-ev.com |
| Compliance certificates: | RoHS, Electromagnetic Compatibility (EMC) |
| Recycling codes: | PAP (Corrugated fiberboard (cardboard), PELD/LDPE (Low-density polyethylene) |
| Safety warning: | Installation and service only by qualified electrician; disconnect from mains before opening; follow manuals |
| Housing material: | Polycarbonate (PC), Glass |
| Display type: | LCD |
| Built-in display: | Yes |
| Charging voltage: | 230/400 V AC (L-N / L-L), 3-phase |
| Suitable for: | Outdoor |
| Number of phases: | 3 |
| Handle(s): | Yes |
| Touchscreen: | Yes |
| Bluetooth: | No |
| Wi-Fi: | Yes |
| Charging current: | 16 A |
| AC input voltage: | 230/400 V AC (L-N / L-L), 3-phase |
| AC input frequency: | 50–60 |
| On/off switch: | No |
| International Protection (IP) code: | IP65 |
| Input current: | 16 A |
| Socket type: | Type 2 |
| Output current: | 16 A |
| Mounting type: | Wall |
| Product colour: | White, Graphite |
| Power cable length: | 5 m |
| Cable entry location: | Rear, Bottom |
| Charging cable length: | 5 m |
| Fault diagnose system: | Yes |
| Output power: | 11 kW |
| Compatible products: | EV/PHEV compliant with IEC 61851‑1 using Type 2 AC charging |
| Package weight: | 3.7 kg |
| Weight: | 2.5 kg |
| Height: | 390 mm |
| Package width: | 310 mm |
| Width: | 230 mm |
| Depth: | 125 mm |
| Package depth: | 510 mm |
| Package height: | 275 mm |
| UN number: | Not applicable / not classified as dangerous good |
| Country of origin: | Poland |
| Customs product code (TARIC): | 8537109170 |
| Export Control Classification Number (ECCN): | EAR99 |
| Warnings: | Before use, make sure the device is correctly installed by a qualified electrician., Disconnect the unit from the power supply during maintenance or servicing., Do not use the unit in a damp or wet environment to avoid the risk of electric shock. |
| Hazard pictogram(s): | GHS05: Corrosive, GHS04: Compressed gas |
