Intel Core i7-14700K processor 33 MB Smart Cache Box
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Intel Core i7 processors |
|---|---|
| Greutate: | 0.09 kg |
| EAN: | 5032037278485 |
| Launch date: | Q4'23 |
| OpenCL version: | 3.0 |
| Status: | Launched |
| Processor codename: | Raptor Lake |
| Stepping: | B0 |
| Processor family: | Intel® Core™ i7 |
| Performance-core base frequency: | 3.4 GHz |
| Processor generation: | Intel® Core™ i7 (14th gen) |
| Processor manufacturer: | Intel |
| Performance cores: | 8 |
| Cooler included: | No |
| Processor model: | i7-14700K |
| Processor base power: | 125 W |
| Processor cores: | 20 |
| Processor operating modes: | 64-bit |
| Processor cache: | 33 MB |
| Processor socket: | LGA 1700 |
| Maximum number of DMI lanes: | 8 |
| Processor threads: | 28 |
| Performance-core boost frequency: | 5.5 GHz |
| Efficient cores: | 12 |
| Memory bandwidth supported by processor (max): | 89.6 GB/s |
| Processor cache type: | Smart Cache |
| Box: | Yes |
| Maximum turbo power: | 253 W |
| Processor ARK ID: | 236783 |
| On-board graphics card model: | Intel UHD Graphics 770 |
| Number of execution units: | 32 |
| Discrete graphics card model: | Not available |
| On-board graphics card DirectX version: | 12.0 |
| On-board graphics card refresh rate at maximum resolution (HDMI): | 60 Hz |
| On-board graphics card maximum resolution (DisplayPort): | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (HDMI): | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort): | 60 Hz |
| On-board graphics card: | Yes |
| On-board graphics card base frequency: | 300 MHz |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel): | 5120 x 3200 pixels |
| On-board graphics card OpenGL version: | 4.5 |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): | 120 Hz |
| Number of displays supported (on-board graphics): | 4 |
| On-board graphics card dynamic frequency (max): | 1600 MHz |
| Discrete graphics card: | No |
| On-board graphics card outputs supported: | Embedded DisplayPort (eDP) 1.4b, HDMI 2.1, DisplayPort 1.4a |
| On-board graphics card ID: | 0xA780 |
| Multi-Format Codec Engines: | 2 |
| PCI Express configurations: | 1x16+1x4, 2x8+1x4 |
| PCI Express slots version: | 4.0, 5.0 |
| CPU configuration (max): | 1 |
| Thermal Monitoring Technologies: | Yes |
| Embedded options available: | No |
| Commodity Classification Automated Tracking System (CCATS): | 740.17B1 |
| Export Control Classification Number (ECCN): | 5A992C |
| Use conditions: | PC/Client/Tablet, Workstation |
| Scalability: | 1S |
| Supported instruction sets: | SSE4.2, SSE4.1, AVX 2.0 |
| Direct Media Interface (DMI) Revision: | 4.0 |
| Thermal solution specification: | PCG 2020A |
| Maximum number of PCI Express lanes: | 20 |
| Idle States: | Yes |
| Execute Disable Bit: | Yes |
| Market segment: | Desktop |
| Non-ECC: | Yes |
| Memory channels: | Dual-channel |
| Maximum internal memory supported by processor: | 192 GB |
| ECC: | Yes |
| Memory bandwidth (max): | 89.6 GB/s |
| Memory types supported by processor: | DDR4-SDRAM, DDR5-SDRAM |
| Tjunction: | 100 °C |
| Processor package size: | 45 x 37.5 mm |
| Enhanced Intel SpeedStep Technology: | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d): | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD): | Yes |
| Intel® Turbo Boost Technology: | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology): | Yes |
| Intel 64: | Yes |
| Intel® AES New Instructions (Intel® AES-NI): | Yes |
| Intel Turbo Boost Max Technology 3.0: | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU: | Yes |
| Intel® OS Guard: | Yes |
| Intel® Standard Manageability (ISM): | Yes |
| Mode-based Execute Control (MBE): | Yes |
| Intel® Speed Shift Technology: | Yes |
| Intel® Quick Sync Video Technology: | Yes |
| Intel® Boot Guard: | Yes |
| Intel® Volume Management Device (VMD): | Yes |
| Intel Virtualization Technology (VT-x): | Yes |
| Intel® Control-flow Enforcement Technology (CET): | Yes |
| Intel® Thread Director: | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency: | 5.6 GHz |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: | Yes |
| Intel VT-x with Extended Page Tables (EPT): | Yes |
| Intel® Secure Key: | Yes |
| Maximum internal memory: | 192 GB |
| Graphics output: | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| L2 cache: | 28672 KB |
| Harmonized System (HS) code: | 8542310001 |
| Warnings: | Avoid shocks and drops so as not to damage delicate components., Do not touch the processor pins to avoid electrostatic damage., Ensure that the processor is adequately cooled to prevent overheating. |
