GIGABYTE X870 AORUS ELITE WIFI7 Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 phases VRM, up to 8000MHz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-AM5 |
|---|---|
| Greutate: | 2.25 kg |
| EAN: | 4719331864811 |
| Warranty period: | 3 year(s) |
| Supported processor sockets: | Socket AM5 |
| Processor manufacturer: | AMD |
| Compatible processor series: | AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series |
| Maximum internal memory supported by processor: | 256 GB |
| Processor socket: | Socket AM5 |
| Parallel processing technology support: | Not supported |
| DirectX version: | 12.0 |
| On-board graphics card: | No |
| PC health monitoring: | Fan, Voltage, Temperature |
| Motherboard form factor: | ATX |
| Windows operating systems supported: | Windows 11 x64 |
| Audio output channels: | 7.1 channels |
| Motherboard chipset: | AMD X870 |
| Audio chip: | Realtek ALC1220 |
| Product colour: | Black |
| Motherboard chipset family: | AMD |
| Supported memory clock speeds: | 6800, 8000, 6000, 5200, 6200, 6666, 6600, 6400, 7600, 7800, 5600, 7200, 4800 MHz, 4400 MHz, 7000, 8200 |
| Maximum internal memory: | 256 GB |
| Supported memory module capacities: | 24GB, 1GB, 32GB, 2GB, 4GB, 8GB, 16GB |
| Supported memory types: | DDR5-SDRAM |
| Memory slots type: | DIMM |
| Number of memory slots: | 4 |
| Memory channels: | Dual-channel |
| Supported memory clock speed (max): | 8200 MHz |
| ECC сompatibility: | Non-ECC |
| Maximum internal memory per slot: | 64 GB |
| Width: | 305 mm |
| Height: | 35 mm |
| Depth: | 244 mm |
| Bluetooth: | Yes |
| LAN controller: | Realtek RTL8125 |
| Bluetooth version: | 5.4 |
| Wi-Fi: | Yes |
| Top Wi-Fi standard: | Wi-Fi 7 (802.11be) |
| Wi-Fi standards: | Wi-Fi 7 (802.11be) |
| Ethernet LAN: | Yes |
| WLAN controller model: | MediaTek MT7925 |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| USB 2.0 connectors: | 2 |
| Number of chassis fan connectors: | 6 |
| EPS power connector (8-pin): | Yes |
| Front panel audio connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Number of SATA III connectors: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| CPU fan connector: | Yes |
| Front panel connector: | Yes |
| TPM connector: | Yes |
| USB 3.2 Gen 2x2 connectors: | 1 |
| RGB LED pin header: | Yes |
| Number of water pump connectors: | 3 |
| Number of EPS power connectors (8-pin): | 2 |
| Number of CPU fan connectors: | 2 |
| Number of RGB LED pin headers: | 4 |
| BIOS type: | UEFI AMI |
| Clear CMOS button: | Yes |
| Clear CMOS jumper: | Yes |
| Desktop Management Interface (DMI) version: | 2.7 |
| Package weight: | 2.74 kg |
| Package width: | 335 mm |
| Package depth: | 270 mm |
| Package height: | 80 mm |
| Batteries included: | Yes |
| Antenna included: | Yes |
| Screws included: | Yes |
| Bundled software: | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Supported storage drive types: | HDD & SSD |
| RAID levels: | 1, 0, 10 |
| Supported storage drive interfaces: | M.2, SATA III |
| RAID support: | Yes |
| Number of storage drives supported: | 8 |
| Number of HDDs supported: | 4 |
| S/PDIF out port: | Yes |
| DisplayPorts quantity: | 2 |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB 2.0 ports quantity: | 2 |
| DisplayPort version: | 1.4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 3 |
| Headphone outputs: | 1 |
| HDMI ports quantity: | 1 |
| Microphone in: | Yes |
| USB4 Gen 2x2 ports quantity: | 2 |
| HDMI version: | 2.1 |
| WiFi-AP antenna jack: | 2 |
| PCI Express x16 (Gen 3.x) slots: | 1 |
| Number of M.2 (M) slots: | 4 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| PCI Express x4 slots: | 2 |
| 2nd M.2 largest key size: | 22110 |
| 1st M.2 largest key size: | 25110 |
| 4th M.2 highest PCI Express generation: | 4.0 |
| 1st M.2 highest PCI Express generation: | 5.0 |
| 3rd M.2 largest key size: | 22110 |
| 3rd M.2 highest PCI Express generation: | 5.0 |
| 2nd M.2 highest PCI Express generation: | 5.0 |
| 4th M.2 largest key size: | 22110 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| Battery weight: | 3 g |
| Battery technology: | Lithium-Manganese Dioxide (LiMnO2) |
| Number of battery cells: | 1 |
| Battery type: | CR2032 |
| Lithium weight per battery: | 0.07 g |
| Weight: | 2.4 kg |
| Country of origin: | China |
| Products per shipping (inner) case: | 1 pc(s) |
| Warnings: | Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty. |
