Gigabyte Rack Platform (1U) AMD R183-Z93
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Server platforms RACK |
|---|---|
| Greutate: | 24.8 kg |
| Processor family: | AMD |
| Number of processors supported: | 2 |
| Processor socket: | LGA 6096 |
| Compatible processor series: | AMD EPYC 9005, AMD EPYC 9004 |
| Processor manufacturer: | AMD |
| Trusted Platform Module (TPM) version: | 2.0 |
| Trusted Platform Module (TPM): | Yes |
| Supported RDIMM clock speeds: | 4800 MHz, 6400 MHz |
| Supported memory types: | DDR5-SDRAM |
| Number of DIMM slots: | 24 |
| Motherboard chipset: | System on Chip |
| Product colour: | Silver, Black |
| Chassis type: | Rack (1U) |
| LED indicators: | Yes |
| Power supply: | 1600 W |
| 80 PLUS certification: | 80 PLUS Titanium |
| Storage relative humidity (H-H): | 20 - 95% |
| Storage temperature (T-T): | -40 - 60 °C |
| Operating temperature (T-T): | 10 - 35 °C |
| Height: | 43.5 mm |
| Depth: | 815 mm |
| Weight: | 22.9 kg |
| Width: | 438 mm |
| Ethernet interface type: | Gigabit Ethernet, 1 Gigabit Ethernet |
| Ethernet LAN: | Yes |
| Ethernet LAN data rates: | 1000 Mbit/s |
| LAN controller: | Intel® I350-AM2 |
| Package weight: | 27.9 kg |
| Package width: | 602 mm |
| Package depth: | 1052 mm |
| Package height: | 267 mm |
| PCI Express x16 (Gen 5.x) slots: | 4 |
| Supported storage drive types: | HDD & SSD |
| Supported storage drive interfaces: | Serial ATA |
| Number of storage drives supported: | 3 |
| Storage drive sizes supported: | M.2, 2.5, 3.5 |
| Number of M.2 connectors: | 3 |
| Number of 2.5"/3.5" bays: | 4 |
| Reset button: | Yes |
| Mini DisplayPorts quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 4 |
| Port Management LAN: | Yes, 1 |
| Warnings: | The product may contain components that are harmful to health, use caution when handling., Do not throw into regular trash, product requires special disposal., Do not disassemble the unit yourself. |
