GIGABYTE B760 GAMING X GEN5 Motherboard - Supports 14th Gen. Intel Core CPUs, 8+1+1 phases VRM, up to 5600MHz DDR5, 3xPCIe 4.0 M.2, 2.5 GbE LAN, USB 3.2 Gen 2
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-1700 |
|---|---|
| Greutate: | 1.552 kg |
| EAN: | 4719331872120 |
| Processor socket: | LGA 1700 |
| Compatible processor series: | Intel Core i3 14th Gen, Intel Core i9 14th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i7 13th Gen, Intel Core i3 12th Gen, Intel® Celeron®, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen |
| Processor manufacturer: | Intel |
| Supported processor sockets: | LGA 1700 |
| HDCP: | Yes |
| Maximum resolution: | 4096 x 2304 pixels |
| Motherboard chipset: | Intel B760 |
| Power source type: | ATX |
| PC health monitoring: | Fan, Temperature, Water cooling, Voltage |
| Motherboard form factor: | ATX |
| Windows operating systems supported: | Windows 11 x64, Windows 10 x64 |
| Audio output channels: | 7.1 channels |
| Motherboard chipset family: | Intel |
| Memory channels: | Dual-channel |
| Memory slots type: | DIMM |
| Supported memory types: | DDR5-SDRAM |
| Number of memory slots: | 4 |
| Supported memory clock speed (max): | 7600 MHz |
| Unbuffered memory: | Yes |
| Supported memory clock speeds: | 5200, 5600, 7200 MHz, 6800, 7600 MHz, 5800, 5400, 7400, 6200, 6400 MHz, 4000, 4800, 6000, 7000 MHz, 6600 |
| Maximum internal memory: | 256 GB |
| ECC сompatibility: | ECC & Non-ECC |
| Maximum internal memory per slot: | 64 GB |
| Width: | 305 mm |
| Depth: | 244 mm |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| Ethernet LAN: | Yes |
| Number of water pump connectors: | 2 |
| TPM connector: | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| Number of EPS power connectors (8-pin): | 1 |
| Number of CPU fan connectors: | 2 |
| RGB LED pin header: | Yes |
| Number of RGB LED pin headers: | 4 |
| 12V power connector: | Yes |
| USB 2.0 connectors: | 2 |
| S/PDIF out connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Front panel audio connector: | Yes |
| Number of SATA III connectors: | 4 |
| CPU fan connector: | Yes |
| EPS power connector (8-pin): | Yes |
| Front panel connector: | Yes |
| Number of chassis fan connectors: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| Clear CMOS jumper: | Yes |
| Desktop Management Interface (DMI) version: | 2.7 |
| BIOS type: | UEFI AMI |
| Number of HDDs supported: | 4 |
| Number of storage drives supported: | 7 |
| RAID levels: | 10, 1, 0, 5 |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2, PCI Express 4.0, SATA III |
| Supported storage drive types: | HDD & SSD |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: | 1 |
| HDMI version: | 2.1 |
| HDMI ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| DisplayPort version: | 1.2 |
| DisplayPorts quantity: | 1 |
| USB 2.0 ports quantity: | 5 |
| 1st M.2 largest key size: | 22110 |
| 1st M.2 highest PCI Express generation: | 4.0 |
| 2nd M.2 largest key size: | 22110 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| PCI Express x16 (Gen 3.x) slots: | 2 |
| Number of M.2 (M) slots: | 3 |
| 3rd M.2 highest PCI Express generation: | 4.0 |
| 3rd M.2 largest key size: | 22110 |
