GIGABYTE B650 EAGLE Motherboard - AMD Ryzen 9000 Series CPUs, 12+2+2 Phases VRM, up to 7600MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 2
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-AM5 |
|---|---|
| Greutate: | 1.695 kg |
| EAN: | 4719331863081 |
| Warranty period: | 3 year(s) |
| Compatible processor series: | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Processor manufacturer: | AMD |
| Supported processor sockets: | Socket AM5 |
| Processor socket: | Socket AM5 |
| Maximum resolution: | 4096 x 2160 pixels |
| HDCP: | Yes |
| DirectX version: | 12.0 |
| Parallel processing technology support: | Not supported |
| PC health monitoring: | Temperature, Voltage, Water cooling, Fan |
| Audio chip: | Realtek ALC897 |
| Product colour: | Bronze |
| Motherboard chipset: | AMD B650 |
| Motherboard form factor: | ATX |
| Motherboard chipset family: | AMD |
| Windows operating systems supported: | Windows 11 x64, Windows 10 x64 |
| Audio output channels: | 7.1 channels |
| Power source type: | ATX |
| Memory slots type: | DIMM |
| Supported memory clock speed (max): | 7600 MHz |
| Supported memory types: | DDR5-SDRAM |
| Maximum internal memory: | 256 GB |
| Number of memory slots: | 4 |
| Unbuffered memory: | Yes |
| Memory channels: | Dual-channel |
| Supported memory clock speeds: | 6600, 7000 MHz, 4400, 6800, 6200, 6000, 6400 MHz, 5200, 7600 MHz, 5600, 7200 MHz, 4800 |
| ECC сompatibility: | Non-ECC |
| Maximum internal memory per slot: | 64 GB |
| Depth: | 244 mm |
| Width: | 305 mm |
| Height: | 35 mm |
| Ethernet interface type: | Gigabit Ethernet |
| Ethernet LAN: | Yes |
| Wi-Fi: | No |
| LAN controller: | Realtek RTL8111H |
| Number of SATA III connectors: | 4 |
| ATX Power connector (24-pin): | Yes |
| Serial port headers: | 1 |
| TPM connector: | Yes |
| Front panel connector: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| CPU fan connector: | Yes |
| Number of chassis fan connectors: | 3 |
| 12V power connector: | Yes |
| RGB LED pin header: | Yes |
| USB 2.0 connectors: | 3 |
| EPS power connector (8-pin): | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| Front panel audio connector: | Yes |
| Number of water pump connectors: | 2 |
| Number of RGB LED pin headers: | 4 |
| Number of CPU fan connectors: | 2 |
| BIOS type: | UEFI AMI |
| Desktop Management Interface (DMI) version: | 2.7 |
| Clear CMOS jumper: | Yes |
| Package width: | 335 mm |
| Package depth: | 270 mm |
| Package height: | 80 mm |
| Package weight: | 1.82 kg |
| Batteries included: | Yes |
| Screws included: | Yes |
| Bundled software: | Norton Internet Security (OEM version) LAN bandwidth management software |
| RAID levels: | 0, 10, 1 |
| Supported storage drive types: | HDD & SSD |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2, SATA III |
| Number of storage drives supported: | 7 |
| Number of HDDs supported: | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 2 |
| HDMI ports quantity: | 1 |
| PS/2 ports quantity: | 1 |
| Microphone in: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: | 1 |
| HDMI version: | 2.1 |
| Headphone outputs: | 1 |
| DisplayPort version: | 1.4 |
| DisplayPorts quantity: | 1 |
| Line-in: | Yes |
| USB 2.0 ports quantity: | 6 |
| Ethernet LAN (RJ-45) ports: | 1 |
| PCI Express x16 (Gen 3.x) slots: | 3 |
| Number of M.2 (M) slots: | 3 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| 2nd M.2 largest key size: | 22110 |
| 3rd M.2 largest key size: | 22110 |
| 1st M.2 highest PCI Express generation: | 5.0 |
| 3rd M.2 highest PCI Express generation: | 4.0 |
| 1st M.2 largest key size: | 25110 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| Battery technology: | Lithium-Manganese Dioxide (LiMnO2) |
| Battery type: | CR2032 |
| Number of battery cells: | 1 |
| Battery weight: | 3 g |
| Lithium weight per battery: | 0.07 g |
| Country of origin: | China |
| Products per shipping (inner) case: | 1 pc(s) |
| Warnings: | Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty. |
