Biostar H61MHV3 motherboard Intel® H61 LGA 1155 (Socket H2) micro ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-1155 |
|---|---|
| Greutate: | 0.58 kg |
| EAN: | 4712960685208 |
| Processor socket: | LGA 1155 (Socket H2) |
| Supported processor sockets: | LGA 1155 (Socket H2) |
| Compatible processor series: | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3, Intel® Pentium®, Intel® Core™ i7 |
| Processor manufacturer: | Intel |
| Audio chip: | Realtek ALC897 |
| PC health monitoring: | Fan, CPU, Voltage, Temperature |
| Windows operating systems supported: | Windows 8.1, Windows 10, Windows 8, Windows 7 |
| Audio output channels: | 7.1 channels |
| Motherboard chipset: | Intel® H61 |
| Motherboard form factor: | micro ATX |
| Motherboard chipset family: | Intel |
| Supported memory types: | DDR3-SDRAM |
| Memory slots type: | DIMM |
| Supported memory module capacities: | 1GB, 2GB, 4GB, 16GB, 8GB, 512MB |
| Memory channels: | Dual-channel |
| Supported memory clock speeds: | 1066, 1600 MHz, 1333 |
| Number of memory slots: | 2 |
| ECC сompatibility: | Non-ECC |
| Height: | 191 mm |
| Width: | 170 mm |
| Ethernet LAN: | Yes |
| Ethernet interface type: | 100 Gigabit Ethernet, 10 Gigabit Ethernet |
| LAN controller: | Realtek RTL8111H |
| USB 2.0 connectors: | 2 |
| Number of SATA II connectors: | 4 |
| Audio connector: | Yes |
| Front panel audio connector: | Yes |
| CPU fan connector: | Yes |
| Number of chassis fan connectors: | 2 |
| Drivers included: | Yes |
| User guide: | Yes |
| Cables included: | SATA |
| Supported storage drive interfaces: | SATA II |
| Number of storage drives supported: | 4 |
| Headphone outputs: | 3 |
| Ethernet LAN (RJ-45) ports: | 1 |
| HDMI ports quantity: | 1 |
| PS/2 ports quantity: | 1 |
| VGA (D-Sub) ports quantity: | 1 |
| USB 2.0 ports quantity: | 4 |
| PCI Express slots version: | 3.0, 2.0 |
| PCI Express x16 (Gen 3.x) slots: | 1 |
| PCI Express x1 (Gen 2.x) slots: | 1 |
| Harmonized System (HS) code: | 84733020 |
