ASUS TUF GAMING B850-PLUS WIFI AMD B850 Socket AM5 ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-AM5 |
|---|---|
| Greutate: | 1.92 kg |
| EAN: | 4711387781609 |
| Compatible processor series: | AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series |
| Supported processor sockets: | Socket AM5 |
| Processor manufacturer: | AMD |
| Processor socket: | Socket AM5 |
| Maximum resolution: | 7680 x 4320 pixels |
| Parallel processing technology support: | Not supported |
| On-board graphics card: | No |
| Product colour: | Black |
| Audio chip: | Realtek ALC1220 |
| Motherboard form factor: | ATX |
| Power source type: | ATX |
| Audio output channels: | 7.1 channels |
| Motherboard chipset: | AMD B850 |
| Motherboard chipset family: | AMD |
| Windows operating systems supported: | Windows 11 |
| Maximum internal memory: | 192 GB |
| Unbuffered memory: | Yes |
| Number of memory slots: | 4 |
| Supported memory types: | DDR5-SDRAM |
| Memory slots type: | DIMM |
| Memory channels: | Dual-channel |
| Supported memory clock speed (max): | 8000 MHz |
| ECC сompatibility: | ECC & Non-ECC |
| Width: | 305 mm |
| Depth: | 244 mm |
| Bluetooth: | Yes |
| Ethernet LAN: | Yes |
| Bluetooth version: | 5.4 |
| Top Wi-Fi standard: | Wi-Fi 7 (802.11be) |
| Wi-Fi: | Yes |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| Wi-Fi standards: | Wi-Fi 7 (802.11be) |
| Thunderbolt headers: | 1 |
| Front panel audio connector: | Yes |
| USB 2.0 connectors: | 2 |
| Number of SATA III connectors: | 4 |
| ATX Power connector (24-pin): | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| CPU fan connector: | Yes |
| Number of RGB LED pin headers: | 3 |
| Number of COM connectors: | 1 |
| Chassis intrusion connector: | Yes |
| RGB LED pin header: | Yes |
| Number of chassis fan connectors: | 4 |
| Front panel connector: | Yes |
| EPS power connector (8-pin): | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| Number of water pump connectors: | 1 |
| Number of CPU fan connectors: | 2 |
| Number of EPS power connectors (8-pin): | 2 |
| BIOS type: | UEFI AMI |
| Clear CMOS button: | Yes |
| Package weight: | 1.81 kg |
| Package width: | 353 mm |
| Package height: | 68 mm |
| Package depth: | 273 mm |
| Cables included: | SATA |
| Antenna included: | Yes |
| RAID levels: | 10, 5, 1, 0 |
| Supported storage drive interfaces: | M.2, SATA III |
| RAID support: | Yes |
| Supported storage drive types: | HDD & SSD |
| Number of HDDs supported: | 4 |
| Number of storage drives supported: | 7 |
| DisplayPorts quantity: | 1 |
| DisplayPort version: | 1.4 |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB 2.0 ports quantity: | 2 |
| WiFi-AP antenna jack: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 4 |
| Headphone outputs: | 1 |
| HDMI ports quantity: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 3 |
| Microphone in: | Yes |
| HDMI version: | 2.1 |
| Line-in: | Yes |
| USB 3.2 Gen 2x2 Type-C ports quantity: | 1 |
| Number of M.2 (M) slots: | 3 |
| 1st M.2 largest key size: | 2280 |
| 3rd M.2 largest key size: | 2280 |
| 3rd M.2 highest PCI Express generation: | 4.0 |
| 2nd M.2 largest key size: | 22110 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| 1st M.2 highest PCI Express generation: | 5.0 |
| PCI Express x1 (Gen 4.x) slots: | 2 |
| Weight: | 1.32 kg |
| Quick installation guide: | Yes |
| Warnings: | Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty. |
