ASUS TUF GAMING B760M-PLUS II Intel B760 LGA 1700 micro ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-1700 |
|---|---|
| Greutate: | 1.5 kg |
| EAN: | 4711387469798 |
| Supported processor sockets: | LGA 1700 |
| Processor socket: | LGA 1700 |
| Compatible processor series: | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3 |
| Processor manufacturer: | Intel |
| Parallel processing technology support: | Not supported |
| Windows operating systems supported: | Windows 11, Windows 10 x64 |
| Audio output channels: | 7.1 channels |
| Motherboard form factor: | micro ATX |
| Motherboard chipset family: | Intel |
| Motherboard chipset: | Intel B760 |
| ECC сompatibility: | Non-ECC |
| Supported memory types: | DDR5-SDRAM |
| Number of memory slots: | 4 |
| Memory slots type: | DIMM |
| Unbuffered memory: | Yes |
| Memory channels: | Dual-channel |
| Supported memory clock speed (max): | 7800 MHz |
| Supported memory clock speeds: | 5000, 7400, 6200, 5600, 7200 MHz, 5200, 5800, 5400, 7600 MHz, 7800, 6600, 6000, 7000 MHz, 6400 MHz, 6800, 4800 |
| Maximum internal memory: | 192 GB |
| Height: | 50 mm |
| Width: | 244 mm |
| Depth: | 244 mm |
| Wi-Fi: | No |
| Ethernet LAN: | Yes |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| 12V power connector: | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| Front panel audio connector: | Yes |
| USB 2.0 connectors: | 3 |
| EPS power connector (8-pin): | Yes |
| Thunderbolt headers: | 1 |
| CPU fan connector: | Yes |
| Number of SATA III connectors: | 4 |
| ATX Power connector (24-pin): | Yes |
| Number of chassis fan connectors: | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| BIOS type: | UEFI AMI |
| Package weight: | 1.65 kg |
| Package width: | 280 mm |
| Package depth: | 265 mm |
| Package height: | 71 mm |
| Screws included: | Yes |
| Cables included: | SATA |
| Number of HDDs supported: | 4 |
| Supported storage drive types: | HDD & SSD |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2, SATA III |
| RAID levels: | 1, 10, 0, 5 |
| Number of storage drives supported: | 7 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
| Ethernet LAN (RJ-45) ports: | 1 |
| DisplayPorts quantity: | 1 |
| HDMI ports quantity: | 1 |
| Headphone outputs: | 1 |
| Microphone in: | Yes |
| S/PDIF out port: | Yes |
| USB 3.2 Gen 2x2 Type-C ports quantity: | 1 |
| USB 2.0 ports quantity: | 4 |
| Number of M.2 (M) slots: | 3 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| PCI Express x4 (Gen 4.x) slots: | 1 |
| PCI Express x1 (Gen 3.x) slots: | 1 |
| Weight: | 982 g |
| Warnings: | Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal. |
