ASUS PRO WS WRX90E-SAGE SE AMD WRX90 Socket sTR5 EEB motherboard for workstations
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | AMD server motherboards |
|---|---|
| Greutate: | 4.69 kg |
| EAN: | 4711387441145 |
| Processor manufacturer: | AMD |
| Processor socket: | Socket sTR5 |
| Windows operating systems supported: | Windows 10 x64, Windows 11 |
| Motherboard chipset family: | AMD |
| Audio chip: | Realtek ALC1220P |
| Component for: | Workstation |
| Motherboard chipset: | AMD WRX90 |
| Motherboard form factor: | EEB |
| Memory channels: | Octa-channel |
| Memory slots type: | DIMM |
| Supported memory types: | DDR5-SDRAM |
| ECC: | Yes |
| Number of memory slots: | 8 |
| Width: | 305 mm |
| Depth: | 330 mm |
| Ethernet LAN: | Yes |
| Wi-Fi: | No |
| Ethernet interface type: | 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| USB 3.2 Gen 2x2 connectors: | 1 |
| USB 2.0 connectors: | 2 |
| Front panel audio connector: | Yes |
| CPU fan connector: | Yes |
| EPS power connector (8-pin): | Yes |
| TPM connector: | Yes |
| Chassis intrusion connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Number of COM connectors: | 1 |
| Number of SATA III connectors: | 4 |
| Number of chassis fan connectors: | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| BIOS type: | UEFI AMI |
| Clear CMOS button: | Yes |
| BIOS memory size: | 256 Mbit |
| Number of HDDs supported: | 4 |
| Supported storage drive interfaces: | M.2, SATA III, SlimSAS |
| RAID levels: | 1, 0, 10, 5 |
| Number of storage drives supported: | 10 |
| RAID support: | Yes |
| Supported storage drive types: | HDD & SSD |
| USB4 Gen 3x2 ports quantity: | 2 |
| USB connector type: | USB Type-C, USB Type-A |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 6 |
| Ethernet LAN (RJ-45) ports: | 2 |
| VGA (D-Sub) ports quantity: | 1 |
| USB 2.0 ports quantity: | 1 |
| PCI Express x16 (Gen 5.x) slots: | 7 |
| Number of M.2 (M) slots: | 4 |
| Mini DisplayPorts quantity: | 2 |
| Warnings: | Use only in a dry and well-ventilated area., Do not open or disassemble the motherboard., The motherboard may contain electronic components hazardous to health - avoid direct contact. |
