ASUS PRIME H610M-A WIFI Intel H610 LGA 1700 micro ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | Motherboards Socket-1700 |
|---|---|
| Greutate: | 1 kg |
| EAN: | 4711387301777 |
| Compatible processor series: | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3 |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1700 |
| Supported processor sockets: | LGA 1700 |
| Parallel processing technology support: | Not supported |
| Motherboard chipset: | Intel H610 |
| Windows operating systems supported: | Windows 11 x64, Windows 10 x64 |
| Audio output channels: | 7.1 channels |
| Motherboard form factor: | micro ATX |
| Motherboard chipset family: | Intel |
| Supported memory types: | DDR5-SDRAM |
| Number of memory slots: | 2 |
| Memory slots type: | DIMM |
| Memory channels: | Dual-channel |
| Supported memory clock speed (max): | 5600 MHz |
| ECC сompatibility: | Non-ECC |
| Supported memory clock speeds: | 5200, 5400, 4800 MHz, 5000, 5600 |
| Unbuffered memory: | Yes |
| Maximum internal memory: | 96 GB |
| Width: | 244 mm |
| Depth: | 216 mm |
| Wi-Fi standards: | Wi-Fi 4 (802.11n), 802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac) |
| Bluetooth version: | 5.0 |
| Ethernet LAN: | Yes |
| Ethernet interface type: | Gigabit Ethernet |
| Wi-Fi: | Yes |
| Top Wi-Fi standard: | Wi-Fi 5 (802.11ac) |
| Bluetooth: | Yes |
| Audio connector: | Yes |
| 12V power connector: | Yes |
| RGB LED pin header: | Yes |
| Front panel audio connector: | Yes |
| S/PDIF out connector: | Yes |
| TPM connector: | Yes |
| EPS power connector (8-pin): | Yes |
| Number of SATA III connectors: | 4 |
| Number of chassis fan connectors: | 2 |
| USB 2.0 connectors: | 2 |
| ATX Power connector (24-pin): | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 2 |
| Number of COM connectors: | 1 |
| CPU fan connector: | Yes |
| BIOS type: | UEFI AMI |
| Clear CMOS button: | Yes |
| Package weight: | 1.07 kg |
| Package depth: | 263 mm |
| Package width: | 270 mm |
| Package height: | 51.5 mm |
| Cables included: | SATA |
| Number of HDDs supported: | 4 |
| Number of storage drives supported: | 6 |
| Supported storage drive interfaces: | M.2, SATA III |
| Supported storage drive types: | HDD & SSD |
| Headphone outputs: | 1 |
| WiFi-AP antenna jack: | 1 |
| HDMI version: | 2.1 |
| Line-in: | Yes |
| VGA (D-Sub) ports quantity: | 1 |
| HDMI ports quantity: | 1 |
| Microphone in: | Yes |
| PS/2 ports quantity: | 2 |
| DisplayPort version: | 1.4 |
| DisplayPorts quantity: | 1 |
| USB 2.0 ports quantity: | 4 |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 1 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| PCI Express x1 (Gen 3.x) slots: | 1 |
| Number of M.2 (M) slots: | 2 |
