ASUS P13R-E Intel C266 LGA 1700 ATX
Descriere detaliată a produsului
Descrierea produsului nu este disponibilă
Parametri suplimentari
| Categorie: | INTEL server motherboards |
|---|---|
| Greutate: | 1.4 kg |
| EAN: | 4711636234283 |
| Supported processor sockets: | LGA 1700 |
| Processor manufacturer: | Intel |
| Compatible processor series: | Intel Xeon 6300, AMD Turion X2 Ultra Dual-Core, Intel Xeon E, Intel® Pentium® |
| Processor socket: | LGA 1700 |
| Parallel processing technology support: | Not supported |
| Component for: | Server |
| Cooling type: | Passive |
| Power source type: | ATX |
| Motherboard form factor: | ATX |
| Product colour: | Black |
| Motherboard chipset family: | Intel |
| PC health monitoring: | CPU, Fan, Temperature |
| Motherboard chipset: | Intel C266 |
| Supported memory clock speed (max): | 4400 MHz |
| Memory slots type: | DIMM |
| Supported memory types: | DDR5-SDRAM |
| Number of memory slots: | 4 |
| Memory channels: | Dual-channel |
| Maximum internal memory per slot: | 32 GB |
| ECC сompatibility: | ECC |
| Supported memory clock speeds: | 4000, 3600, 4400 MHz |
| Maximum internal memory: | 128 GB |
| Operating temperature (T-T): | 10 - 50 °C |
| Storage relative humidity (H-H): | 20 - 90% |
| Storage temperature (T-T): | -40 - 70 °C |
| Width: | 305 mm |
| Depth: | 244 mm |
| Height: | 68 mm |
| Ethernet LAN: | Yes |
| Wi-Fi: | No |
| Ethernet interface type: | Gigabit Ethernet |
| EPS power connector (8-pin): | Yes |
| Number of chassis fan connectors: | 6 |
| Number of COM connectors: | 1 |
| TPM connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Front panel connector: | Yes |
| Chassis intrusion connector: | Yes |
| 12V power connector: | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| Number of EPS power connectors (8-pin): | 1 |
| Number of SATA III connectors: | 8 |
| USB 2.0 connectors: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| Package height: | 78 mm |
| Package depth: | 281 mm |
| Package weight: | 1.5 kg |
| Package width: | 341 mm |
| Number of HDDs supported: | 8 |
| Number of storage drives supported: | 10 |
| Supported storage drive types: | HDD & SSD |
| Supported storage drive interfaces: | PCI Express 4.0, SATA III |
| USB 2.0 ports quantity: | 2 |
| Ethernet LAN (RJ-45) ports: | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 4 |
| VGA (D-Sub) ports quantity: | 1 |
| Number of M.2 (M) slots: | 2 |
| PCI Express x4 (Gen 4.x) slots: | 2 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
| PCI Express x8 (Gen 5.x) slots: | 1 |
| 1st M.2 largest key size: | 22110 |
| 1st M.2 highest PCI Express generation: | 4.0 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| 2nd M.2 largest key size: | 22110 |
| Weight: | 800 g |
